• Design and Detail Draughting Services

    2D and 3D Computer Aided Design and Draughting

    Redgate Engineering - your reliable source of professional trouble free draughting.

  • Redgate Engineering - your reliable source of professional trouble free draughting.

    Redgate Engineering provide a reliable and professional drawing service to engineering, construction and manufacturing companies as well as drawing offices and inventors.

    We specialise in metalwork fabrication. We are with you all the way from initial concept, through to general arrangement drawings and final detailed manufacturing drawings.

    Based in Yorkshire but with clients nationwide we provide a flexible, on-demand support service that starts with us seeking a full understanding of your requirements. We develop flexible and tailor-made solutions for all budgets. We have strict quality checks in place to ensure the highest standards before delivery. Using the latest CAD technology provides 100% precision. By generating detailed 2D drawing sets we provide all the information erectors need for building structures on site. Our aim is 100% satisfaction and we stand firmly behind every project we work on.

    Detailed Drawing Plans prepared for:

    • Platforms
    • Fire escapes
    • Staircases and balustrades
    • Canopies
    • Balconies
    • General steel fabrication
    • Structural steelwork
